Baumfolder BAUM1620 Gapset Calibration - Manual (Page 8)

8
Recalibrating
Fold
Roll
Pressures
for
Fold
Roll
Wear:
Safety:
1. It
is
recommended
to
shut
incoming
power
off
to
the
folder
by
using
the
main
power
disconnect
located
on
the
parallel
unit
or
disconnecting
power
to
the
machine
by
unplugging
it
from
any/all
power
source(s).
2. Due
to
possible
injury,
never
attempt
or
allow
anyone
to
attempt
to
set
the
fold
roll
gapsets
while
the
fold
rolls
are
running.
Adjusting
fold
rolls
due
to
normal
wear
and
tear
on
the
folder
is
common.
Recalibrating
the
fold
rolls
for
this
is
very
easy.
1. Remove
plastic
caps
from
the
top
of
all
of
the
gapset
knobs.
2. Loosen
the
nuts
in
all
of
the
gapset
knob
cavity
using
a
½”
or
13mm
nut
driver.
3. Place
(1)
1”
wide
strip
of
20#
bond
paper
towards
the
outer
portion
of
the
main
and
#1
fold
rolls
ensuring
that
the
paper
is
making
full
contact
with
the
urethane
bands
of
the
fold
rolls.
Plastic
Binder
Plug
Set
Screw
Cap
Gapset
Knob
Gapset
Setting
Dial
Indicator
w/
Label
Foldhead
Frame
Fold
Roll
Elastic
Stop
Nut
Gapset
Rod/Block
Weldment
