Fan motor electrical data, Defrost heater electrical data, Refrigerant operating charge – Bally Refrigerated Boxes BC Air, Electric, and Hot Gas Defrost Blast Coolers User Manual
Page 3
DEFROST HEATER ELECTRICAL DATA
REFRIGERANT OPERATING CHARGE
FAN MOTOR ELECTRICAL DATA
M.C.A. = Minimum Circuit Ampacity
M.O.P. = Maximum Overcurrent Protection
Refrigerant charge with 30% full coil @ 20°F S.S.T.
- 3 -
AIR
DEFROST
MODEL
NO.
HOT GAS AND
ELECTRIC MODEL
NO.
H 208-230/3/60
K 460/3/60
L 575/3/60
Fan
Motor
Qty/HP
Type of
Motor
Total
F.L.A.
M.C.A.
M.O.P.
Total
F.L.A.
M.C.A. M.O.P.
Total
F.L.A.
M.C.A.
M.O.P.
BC
085A
053
059
064
2/1
Std. Open
Drip Proof
8.4 / 8.0
9.5
15
4.0
4.5
15
3.0
3.4
15
100A 066
072
077
115A 078
085
089
Optional
TEFC
8.4 / 8.0
9.5
15
4.0
4.5
15
3.2
3.6
15
125A
091
097
101
BC
140A 094
103
110
3/1
Std. Open
Drip Proof
Optional
TEFC
12.6 / 12.0
12.6 /12.0
13.7
13.7
20
20
12.0
12.0
13.0
13.0
20
20
4.5
4.8
4.9
5.2
15
15
160A
112
120
126
180A
129
138
143
H 208-230/3/60
K 460/3/60
L 575/3/60
ELECTRIC
DEFROST
MODEL NO.
Fan
Motor
No.
Total heater
kW
Total
F.L.A.
M.C.A.
M.O.P.
Total
F.L.A.
M.C.A.
M.O.P.
Total
F.L.A.
M.C.A.
M.O.P.
053
059 064
2
14.0
38.1/42.2
40/48
50/60
21.1
24
30
16.9
20
25
066
072 077
2
19.6
48/53.1
48/56
60/70
26.5
28
35
21.2
24
30
078
085 089
2
22.4
57.2/63.3
64/64
80/80
31.6
32
40
25.3
28
35
091
097 101
2
22.4
57.2/63.3
64/64
80/80
31.6
32
40
25.3
28
35
094
103 110
3
22.4
57.2/63.3
64/64
80/80
31.6
32
40
25.3
28
35
112
120 126
3
25.2
57.2/63.3
64/64
80/80
31.6
32
40
25.3
28
35
129
138 143
3
28.0
67/74.1
72/80
90/100
37.0
40
50
29.6
32
40
AIR
DEFROST
MODEL NO.
HOT GAS AND ELECTRIC
DEFROST MODEL NO.
R-404A
R-22
R-502
lb
kg
lb
kg
lb
kg
085
053
059
064
35.2
16.0
39.1
17.8
40.4
18.3
100
066
072
077
46.1
21.0
51.4
23.4
53.0
24.1
115
078
085
089
57.2
26.0
63.7
29.0
65.6
29.8
125
091
097
101
68.2
31.0
75.9
34.5
78.2
35.6
140
094
103
110
63.7
29.0
71.0
32.3
73.2
33.3
160
112
120
126
76.9
35.0
85.6
38.9
88.3
40.1
180
129
138
143
92.4
42.0
102.8
46.7
106.0
48.2
