EN-6
Product Overview
Front View
No. Item Description
1 USB 2.0 port
(USB-B) Connect USB storage devices such as USB flash drive or
external hard disk drive.
2 Memory card slot Insert a memory card.
3 Mode switch Slide to switch to different mode.
4 One Touch Backup
button Press to transfer data between a memory card / USB
flash drive to an external hard drive.
5 Status LEDs Indicate the system operation status.
Rear View
No. Item Description
1 Reset hole Insert the pointed object to reboot the system.
2 Micro USB port Connect a USB cable to charge the battery.
3 Ethernet port Connect to a local area network (LAN) using a RJ-45
cable.
4 USB 2.0 port
(USB-A) Connect USB storage devices such as USB flash drive or
external hard disk drive.
