3.1 Connectors:
Lemo Socket (mating cable connector FGG/JGG.0B.305.xxx):
pin 1 Ground
pin 2 LTC in
pin 3 ASCII in/out
pin 4 6-16 volt input Tune reference out 1.92 MHz
pin 5 LTC out
USB connector for setup or firmware upgrade, type mini-A
3.2 Dimensions Input/output voltagesS
• Size
100mm X 74mm X 26mm
• Weight
250 Grms without batteries
• TC input
0.1 to 5 volts pp
• TC output BNC
1 volts pp
• Video out
1 volt pp on 75 Ohm
3.3 Accessories
Supplied accessories:
- Pouch ACL-T
- BNC to BNC cable approx. 40 cm.
Optional accessories:
- Time code cable in XLR-3F / Lemo-5
- Time code cable in BNC / Lemo-5 (To jam from Digibeta camera with BNC
output socket)
- Time code cable out Lemo-5 to XLR-3M
