HD10AMA Mini-Converter v1.0r2 www.aja.com 9
DIP Switch Settings
DIP switch settings used to configure various functions are described below.
Table 1. HD10AMA DIP Switch Setting Descriptions
SWITCH FUNCTION DIP Set LEFT (default) DIP Set RIGHT
1 Audio Embedding
for Channels 1/2
(EMBD 1/2) (ON) Overwrite or embed
new channel 1/2 packets. (OFF) If AUX Jumper is OPEN
(default): Pass any channel 1/2
packets from input SDI.
If AUX Jumper is CLOSED:
Delete all packets from input
SDI.
2 Audio Embedding
for Channels 3/4
(EMDB 3/4) (ON) Overwrite or embed
new channel 3/4 packets. (OFF) If AUX Jumper is OPEN
(default): Pass any channel 3/4
packets from input SDI.
If AUX Jumper is CLOSED:
Delete all packets from input
SDI.
3 Channel Mapping
For Low Embedded
Groups
(EMBD GRP L) Switches 3 and 4 operate together to determine
Embedded channel mapping.
1 represents a Left DIP switch position
0 represents a Right DIP switch position
Refer to Table 2, “Embedded Output Channel Mapping,”
on page 10 for specific settings.
4 Channel Mapping
For High Embedded
Groups
(EMBD GRP H)
5 Channel Mapping
For Low
Disembedding
Groups
(DISEMBD GRP L) Switches 5 and 6 operate together to determine
Disembedded channel mapping.
1 represents a Left DIP switch position
0 represents a Right DIP switch position
Refer to Table 3, “Disembedded Input Channel
Mapping,” on page 11 for specific settings.
6 Channel Mapping
For High
Disembedding
Groups
(DISEMBD GRP H)
7 Professional Or
Consumer Audio
Levels (LEVEL).
Affects all 4 Inputs
and Outputs Use Professional Levels
(PRO) Use Consumer Levels
(CSMR)
Switches 7 and 8 operate together to determine
audio levels. See
Table 4, “Output Level Selection
Matrix For Switches 7 and 8,” on page 12 .
8 High or Low Audio
Levels (LEVEL).
Affects all 4 Inputs
and Outputs Use High Levels (H) Use Low Levels (L)
Switches 7 and 8 operate together to determine
audio levels. See
Table 4, “Output Level Selection
Matrix For Switches 7 and 8,” on page 12 .
