Chapter 1: introduction, Overview, Features – AJA HD10AMA User Manual
Page 4: Overview features
HD10AMA Mini-Converter v1.0r2
www.aja.com
4
Chapter 1: Introduction
Overview
The HD10AMA is a dual rate 4 channel analog audio Embedder/Disembedder. The
Disembedder is always functional providing 4 outputs. The Embedder is user selectable,
on a channel pair basis, to either “pass” input audio or embed input audio from the
breakout cable. Analog audio levels are selectable. The HD10AMA automatically detects
and configures to the input video standard.
Features
• Dual rate HD-SDI/SDI Embedder/Disembedder
• 4 Channel Balanced Analog Audio I/O
• Supplied XLR breakout cable
• HD/SD SDI input, 2 HD/SD SDI outputs
• Dipswitch configuration
• Uses universal input +5V power supply AJA model DWP-U-R1 (included)
