Table 4, “output level selection – AJA HD10AMA User Manual
Page 12
HD10AMA Mini-Converter v1.0r2
www.aja.com
12
The following table shows the combinations of DIP switch settings required to configure
the audio output levels shown.
Table 4. Output Level Selection Matrix For Switches 7 and 8
DIP SW 7
DIP SW 8
In/Out Level Range
Nominal
(-20dBFS)
Full Scale
(0dBFS)
Left
(PRO)
Left
(H)
Professional High (US)
+4dBu
+24dBu
Left
(PRO)
Right
(L)
Professional Low (European)
-2dBu
+18dBu
Right
(CSMR)
Left
(H)
Consumer High
-8dBu
+12dBu
Right
(CSMR)
Right
(L)
Consumer Low
-14dBu
+6dBu
