Network
• 10/100/1000 Ethernet (RJ45)
• 802.11b/g wireless transceiver
• Embedded webserver for remote control
Panel User Interface
• 2 x 20 character display, with dedicated buttons
Timecode
• LTC timecode input and output via BNC
• SDI embedded RP188 timecode
Control
• LANC Loop (2 LANC connectors)—not supported prior to Version 3.0
• Lens Tap: connects to optional AJA Lens Tap intercept cable placed between camera
body and lens for start/stop control—not yet supported by firmware.
• IEEE-1394a/FireWire 400 for control and timecode data, not supported prior to v 3.0
Serial Port
RS-422 (slave pinout), 9-pin (available beginning with version 2.0 firmware).
Connector
pinout is as follows:
FireWire
IEEE-1394b, FireWire™ 800Mb/s connects to FireWire 800-equipped Macintosh
computers (mount as hard drive)—not supported prior to Version 3.0
1
GND
2
TX -
3
RX +
4
GND
5
No Connection
6
GND
7
TX +
8
RX -
9
GND
Shell
GND
