HEAT PUMP HEATING PERFORMANCE -- CONTINUED
INDOOR AIR
OUTDOOR COIL ENTERING AIR TEMPERATURES deg F
---3
7
17
27
37
47
57
67
EDB
CFM
Capacity
MBtuh
Total
Sys-
tem
KW†
Capacity
MBtuh
Total
Sys-
tem
KW†
Capacity
MBtuh
Total
Sys-
tem
KW†
Capacity
MBtuh
Total
Sys-
tem
KW†
Capacity
MBtuh
Total
Sys-
tem
KW†
Capacity
MBtuh
Total
Sys-
tem
KW†
Capacity
MBtuh
Total
Sys-
tem
KW†
Capacity
MBtuh
Total
Sys-
tem
KW†
Total
In-
teg*
Total
In-
teg*
Total
In-
teg*
Total
In-
teg*
Total
In-
teg*
Total
In-
teg*
Total
In-
teg*
Total
In-
teg*
213RNA042---A Outdoor Section With FC4DNF042 Indoor Section
65
1225 16.93 15.57
2.59
21.12 19.41
2.71
25.62 23.36
2.82
30.49 27.08
2.96
35.96 32.73
3.12
42.05 42.05
3.31
49.11 49.11
3.55
57.15 57.15
3.84
1400 17.18 15.81
2.62
21.39 19.66
2.72
25.91 23.63
2.82
30.84 27.39
2.94
36.39 33.11
3.09
42.57 42.57
3.26
49.79 49.79
3.49
57.36 57.36
3.68
1575 17.41 16.02
2.64
21.63 19.88
2.74
26.17 23.86
2.83
31.16 27.67
2.94
36.78 33.47
3.08
43.01 43.01
3.24
50.31 50.31
3.46
57.19 57.19
3.60
70
1225 16.47 15.15
2.70
20.71 19.04
2.83
25.24 23.01
2.95
30.10 26.73
3.09
35.49 32.29
3.26
41.54 41.54
3.46
48.41 48.41
3.70
56.37 56.37
4.01
1400 16.73 15.39
2.72
21.00 19.29
2.84
25.54 23.29
2.95
30.42 27.02
3.07
35.90 32.67
3.22
42.00 42.00
3.41
49.08 49.08
3.63
56.87 56.87
3.87
1575 16.97 15.61
2.75
21.24 19.52
2.85
25.80 23.52
2.95
30.71 27.28
3.07
36.25 32.99
3.21
42.42 42.42
3.38
49.58 49.58
3.60
56.90 56.90
3.77
75
1225 15.94 14.67
2.80
20.29 18.65
2.95
24.86 22.66
3.09
29.73 26.40
3.23
35.02 31.87
3.40
41.01 41.01
3.61
47.74 47.74
3.86
55.57 55.57
4.19
1400 16.21 14.92
2.83
20.57 18.90
2.96
25.15 22.93
3.08
30.05 26.69
3.21
35.42 32.24
3.37
41.50 41.50
3.56
48.38 48.38
3.79
56.31 56.31
4.07
1575 16.46 15.14
2.85
20.82 19.13
2.98
25.42 23.17
3.09
30.33 26.94
3.21
35.77 32.55
3.35
41.90 41.90
3.53
48.90 48.90
3.75
56.49 56.49
3.96
Heating Indoor Model
Capacity
Power
Furnace Model
*FC4DN(F,B)042
1.00
1.00
FA4CN(F,C)048
1.02
1.04
FC4DN(F,B)042
1.00
1.00
FC4DN(F,B)048
1.00
0.95
FK4DNB006
0.99
0.94
FK4DNF003
0.96
1.01
FK4DNF005
0.98
0.96
CAR**4817A**
1.01
1.02
CAR**4821A**
1.01
1.03
CAR**4824A**
1.01
1.03
CNRH*4821A**
1.01
1.03
CNRV*4821A**
1.01
1.03
CNRV*4824A**
1.01
1.03
CSRH*4812A**
1.01
1.02
CNRH*4221A**
0.98
1.02
315(A,J)AV036070
CNRH*4821A**
0.99
1.01
315(A,J)AV036070
CSRH*4212A**
0.98
1.00
315(A,J)AV036070
CSRH*4812A**
0.99
1.01
315(A,J)AV036070
CAR**4817A**
0.99
0.99
315(A,J)AV048090
CNRH*4221A**
0.96
0.99
315(A,J)AV048090
CNRH*4821A**
0.98
0.98
315(A,J)AV048090
CSRH*4212A**
0.98
0.98
315(A,J)AV048090
CSRH*4812A**
0.99
0.99
315(A,J)AV048090
CAR**4221A**
0.98
1.01
315(A,J)AV060110
CAR**4821A**
0.98
0.98
315(A,J)AV060110
CNRH*4221A**
0.96
0.98
315(A,J)AV060110
CNRH*4821A**
0.98
0.98
315(A,J)AV060110
CNRV*4221A**
0.96
0.98
315(A,J)AV060110
CNRV*4821A**
0.98
0.98
315(A,J)AV060110
CSRH*4212A**
0.98
0.98
315(A,J)AV060110
CSRH*4812A**
0.99
0.99
315(A,J)AV060110
CAR**4224A**
0.96
0.99
315(A,J)AV066135
CAR**4824A**
0.98
0.97
315(A,J)AV066135
CNRH*4221A**
0.96
0.98
315(A,J)AV066135
CNRH*4821A**
0.98
0.97
315(A,J)AV066135
CNRV*4824A**
0.98
0.97
315(A,J)AV066135
CSRH*4212A**
0.98
0.97
315(A,J)AV066135
CSRH*4812A**
0.98
0.97
315(A,J)AV066135
CAR**4224A**
0.96
0.99
315(A,J)AV066155
CAR**4824A**
0.98
0.97
315(A,J)AV066155
CNRH*4221A**
0.96
0.98
315(A,J)AV066155
CNRH*4821A**
0.98
0.97
315(A,J)AV066155
CNRV*4824A**
0.98
0.97
315(A,J)AV066155
CSRH*4212A**
0.98
0.97
315(A,J)AV066155
CSRH*4812A**
0.98
0.97
315(A,J)AV066155
Heating Indoor Model
Capacity
Power
Furnace Model
CAR**4224A**
0.98
1.03
355AAV042040
CAR**4824A**
0.99
1.01
355AAV042040
CNRH*4221A**
0.98
1.02
355AAV042040
CNRH*4821A**
0.99
1.01
355AAV042040
CNRV*4824A**
0.99
1.01
355AAV042040
CSRH*4212A**
0.98
1.00
355AAV042040
CSRH*4812A**
0.99
1.01
355AAV042040
CAR**4817A**
0.99
1.00
355AAV042060
CNRH*4221A**
0.98
1.01
355AAV042060
CNRH*4821A**
0.98
0.99
355AAV042060
CSRH*4212A**
0.98
0.99
355AAV042060
CSRH*4812A**
0.99
1.00
355AAV042060
CAR**4221A**
0.98
1.03
355AAV042080
CAR**4821A**
0.99
1.02
355AAV042080
CNRH*4221A**
0.98
1.02
355AAV042080
CNRH*4821A**
0.99
1.01
355AAV042080
CNRV*4221A**
0.98
1.02
355AAV042080
CNRV*4821A**
0.99
1.01
355AAV042080
CSRH*4212A**
0.98
1.00
355AAV042080
CSRH*4812A**
0.99
1.01
355AAV042080
CAR**4221A**
0.98
1.02
355AAV060080
CAR**4821A**
0.99
1.01
355AAV060080
CNRH*4221A**
0.98
1.01
355AAV060080
CNRH*4821A**
0.99
1.00
355AAV060080
CNRV*4221A**
0.98
1.01
355AAV060080
CNRV*4821A**
0.99
1.00
355AAV060080
CSRH*4212A**
0.98
0.99
355AAV060080
CSRH*4812A**
0.99
1.00
355AAV060080
CAR**4221A**
0.98
1.02
355AAV060100
CAR**4821A**
0.98
0.99
355AAV060100
CNRH*4221A**
0.98
1.00
355AAV060100
CNRH*4821A**
0.98
0.98
355AAV060100
CNRV*4221A**
0.98
1.00
355AAV060100
CNRV*4821A**
0.98
0.98
355AAV060100
CSRH*4212A**
0.98
0.99
355AAV060100
CSRH*4812A**
0.99
0.99
355AAV060100
CAR**4224A**
0.98
1.02
355AAV060120
CAR**4824A**
0.98
0.99
355AAV060120
CNRH*4221A**
0.96
0.99
355AAV060120
CNRH*4821A**
0.98
0.99
355AAV060120
CNRV*4824A**
0.98
0.99
355AAV060120
CSRH*4212A**
0.98
0.99
355AAV060120
CSRH*4812A**
0.98
0.98
355AAV060120
