Bryant LEGACY 213R - Manual (Page 23)

23
DETAILED COOLING CAPACITIES -- CONTINUED
EVAPORATOR AIR
CONDENSER ENTERING AIR TEMPERATURES deg F
75 85 95 105 115 125
CFM EWB
Capacity
MBtuh†
Total
System
KW**
Capacity
MBtuh†
Total
System
KW**
Capacity
MBtuh†
Total
System
KW**
Capacity
MBtuh†
Total
System
KW**
Capacity
MBtuh†
Total
System
KW**
Capacity
MBtuh†
Total
System
KW** Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡
213RNA048--A Outdoor Section With FC4DNF048 Indoor Section
1400
72 54.52 28.06 3.28 52.55 27.30 3.65 50.50 26.51 4.06 48.34 25.68 4.51 46.08 24.83 5.01 43.71 23.94 5.55
67 49.39 34.55 3.25 47.56 33.76 3.62 45.65 32.94 4.03 43.64 32.09 4.47 41.55 31.21 4.97 39.34 30.29 5.50
63 45.73 33.33 3.23 44.01 32.53 3.59 42.20 31.71 4.00 40.31 30.85 4.45 38.33 29.95 4.93 36.24 29.02 5.46
62 44.91 41.01 3.22 43.25 40.17 3.59 41.51 39.29 4.00 39.70 38.34 4.44 37.84 37.31 4.93 35.99 35.99 5.45
57 43.46 43.46 3.22 42.11 42.11 3.58 40.70 40.70 3.99 39.21 39.21 4.44 37.64 37.64 4.93 35.99 35.99 5.45
1600
72 55.63 29.41 3.34 53.59 28.64 3.71 51.45 27.83 4.12 49.21 27.00 4.58 46.87 26.13 5.07 44.41 25.23 5.61
67 50.39 36.73 3.31 48.49 35.93 3.68 46.50 35.09 4.09 44.42 34.22 4.54 42.25 33.32 5.03 39.98 32.39 5.56
63 46.66 35.37 3.29 44.88 34.56 3.65 43.00 33.71 4.06 41.04 32.84 4.51 38.99 31.92 4.99 36.84 30.97 5.52
62 45.97 43.87 3.28 44.27 42.96 3.65 42.52 41.96 4.06 40.75 40.75 4.51 39.08 39.08 5.00 37.34 37.34 5.53
57 45.23 45.23 3.28 43.81 43.81 3.65 42.32 42.32 4.06 40.74 40.74 4.51 39.09 39.09 5.00 37.34 37.34 5.53
1800
72 56.49 30.69 3.40 54.38 29.90 3.77 52.18 29.09 4.18 49.87 28.24 4.64 47.46 27.37 5.13 44.93 26.46 5.67
67 51.16 38.81 3.37 49.20 37.99 3.74 47.15 37.14 4.15 45.02 36.26 4.60 42.79 35.34 5.09 40.46 34.37 5.62
63 47.39 37.31 3.35 45.54 36.48 3.71 43.61 35.62 4.12 41.60 34.72 4.57 39.50 33.79 5.05 37.30 32.81 5.58
62 46.92 46.37 3.34 45.24 45.24 3.71 43.67 43.67 4.12 42.02 42.02 4.57 40.29 40.29 5.06 38.46 38.46 5.60
57 46.72 46.72 3.34 45.23 45.23 3.71 43.67 43.67 4.12 42.02 42.02 4.57 40.29 40.29 5.06 38.47 38.47 5.60
Cooling Indoor Model Capacity Power Furnace Model
*FC4DN(F,B)048 1.00 1.00
FC4DN(F,B)048 1.00 1.00
FC4DN(F,B)060 1.02 1.00
FK4DNB006 1.01 0.97
FK4DNF005 0.99 0.97
CAR**4817A** 0.94 0.95 315(A,J)AV048090
CNRH*4821A** 0.97 0.99 315(A,J)AV048090
CNRH*6024A** 0.98 0.98 315(A,J)AV048090
CSRH*4812A** 0.97 0.99 315(A,J)AV048090
CSRH*6012A** 0.99 0.97 315(A,J)AV048090
CAR**4821A** 0.96 0.97 315(A,J)AV060110
CAR**6021A** 0.99 0.97 315(A,J)AV060110
CNRH*4821A** 0.97 0.97 315(A,J)AV060110
CNRH*6024A** 0.99 0.97 315(A,J)AV060110
CNRV*4821A** 0.96 0.96 315(A,J)AV060110
CSRH*4812A** 0.96 0.96 315(A,J)AV060110
CSRH*6012A** 0.99 0.97 315(A,J)AV060110
CAR**4824A** 0.97 0.97 315(A,J)AV066135
CAR**6024A** 0.99 0.97 315(A,J)AV066135
CNRH*4821A** 0.97 0.97 315(A,J)AV066135
CNRH*6024A** 0.99 0.97 315(A,J)AV066135
CNRV*4824A** 0.97 0.97 315(A,J)AV066135
CNRV*6024A** 0.99 0.97 315(A,J)AV066135
CSRH*4812A** 0.96 0.96 315(A,J)AV066135
CSRH*6012A** 0.99 0.97 315(A,J)AV066135
CAR**4824A** 0.97 0.97 315(A,J)AV066155
CAR**6024A** 0.99 0.97 315(A,J)AV066155
CNRH*4821A** 0.97 0.95 315(A,J)AV066155
CNRH*6024A** 0.99 0.97 315(A,J)AV066155
CNRV*4824A** 0.97 0.95 315(A,J)AV066155
CNRV*6024A** 0.99 0.97 315(A,J)AV066155
CSRH*4812A** 0.97 0.95 315(A,J)AV066155
CSRH*6012A** 0.99 0.97 315(A,J)AV066155
CAR**4821A** 0.96 0.97 355AAV060080
CAR**6021A** 0.98 0.98 355AAV060080
CNRH*4821A** 0.96 0.97 355AAV060080
CNRH*6024A** 0.98 0.98 355AAV060080
CNRV*4821A** 0.96 0.97 355AAV060080
CSRH*4812A** 0.96 0.97 355AAV060080
CSRH*6012A** 0.98 0.98 355AAV060080
CAR**4821A** 0.96 0.97 355AAV060100
CAR**6021A** 0.99 0.99 355AAV060100
CNRH*4821A** 0.96 0.97 355AAV060100
CNRH*6024A** 0.98 0.98 355AAV060100
CNRV*4821A** 0.96 0.97 355AAV060100
CSRH*4812A** 0.96 0.97 355AAV060100
CSRH*6012A** 0.99 0.99 355AAV060100
CAR**4824A** 0.96 0.97 355AAV060120
CAR**6024A** 0.98 0.98 355AAV060120
CNRH*4821A** 0.96 0.97 355AAV060120
CNRH*6024A** 0.98 0.98 355AAV060120
CNRV*4824A** 0.96 0.97 355AAV060120
CNRV*6024A** 0.98 0.98 355AAV060120
CSRH*4812A** 0.96 0.97 355AAV060120
CSRH*6012A** 0.99 0.97 355AAV060120
See notes on pg. 24
213R
