11
MODEL 340MAV AND 350MAV DIAGNOSTIC CHART
(See Fig. 3.)
NOTES:
1. Light on continuously means control has power and working properly.
2. The fault code is a 2-digit number. The first digit is determined by the number of short flashes of the light and the second digit is determined by number of long flashes
of the light.
FAULT
CODE
FAULT CODE DESCRIPTION CHECKLIST
13 or 33 Limit Switch Lockout
Check for dirty air filter.
Check for blocked return-air or supply-air grilles.
14 or 34
Ignition Lockout or
Ignition Proving Fault
Check to be sure manual shutoff valve in gas supply pipe is in the open position. (Follow
start-up procedure if you open gas line.)
NOTE: Turn off the electrical supply and remove access doors before continuing with this
checklist.
Check to be sure control switch or knob on gas valve is in ON position. (Follow start-up pro-
cedures if you must reset switch or knob to ON position.)
Check for disconnected ground wire.
24 Furnace Fuse Open Check for blown fuse and possible short in 24-v wiring.
31 Pressure Switch Not Closed
Check to make sure that all PVC pipes leading into the combustion-air intake and vent/
exhaust are free from any cracks and sags. Also check the combustion-air intake and vent/
exhaust pipes on the outside of your home for blockage.
Check for low propane gas pressure.
12, 21, 22,
or 23
Any Other Fault Code Call dealer for service.
No Fault
Code
Signaled
Furnace Fails to Operate and No
Fault is Signaled
Check thermostat for proper temperature setting.
Check for blown fuses and circuit breakers.
Check to be sure blower access panel is properly in place.
MODEL 352MAV DIAGNOSTIC CHART
(See Fig. 3.)
NOTES:
1. Light on continuously means control has power and working properly.
2. The fault code is a 2-digit number. The first digit is determined by the number of short flashes of the light and the second digit is determined by number of long flashes
of the light.
FAULT
CODE
FAULT CODE DESCRIPTION CHECKLIST
13 or 33 Limit Switch Lockout
Check for dirty air filter.
Check for blocked return-air or supply-air grilles.
14 or 34
Ignition Lockout or
Ignition Proving Fault
Check to be sure manual shutoff valve in gas supply pipe is in the open position. (Follow
start-up procedure if you open gas line.)
NOTE: Turn off the electrical supply and remove access doors before continuing with this
checklist.
Check to be sure control switch on gas valve is in ON position. (Follow start-up procedures if
you must reset switch to ON position.)
Check for disconnected ground wire.
24 Furnace Fuse Open Check for blown fuse and possible short in 24-v wiring.
31, 32, 43 Pressure Switch Fault
Check to make sure that all PVC pipes leading into the combustion-air intake and vent/
exhaust are free from any cracks and sags. Also check the combustion-air intake and vent/
exhaust pipes on the outside of your home for blockage.
Check for low propane gas pressure.
12, 21, 22,
23 or 45
Any Other Fault Code Call dealer for service.
No Fault
Code
Signaled
Furnace Fails to Operate and No
Fault is Signaled
Check thermostat for proper temperature setting.
Check for blown fuses and circuit breakers.
Check to be sure blower access panel is properly in place.
