MODEL # 477

IMPORTANT!! PLEASE READ ENTIRE INSTRUCTION SHEET BEFORE ASSEMBLY!!

Step 1:Identify all parts packed in the carton against the parts list.
Remove all protective materials. Set the parts on a flat,
non-abrasive surface. If you are missing any parts or are
unsure as to how to proceed with assembly please contact
our Customer Service Center immediately at 1-800-416-3511.
Do not attempt to assemble if any parts are missing or
damaged.

Step 2:Gently insert the extension pole into the base. Using the
bolts provided, gently guide them through the bottom of
the umbrella base and into the holes that are pre-drilled
in the extension pole. Check the bolts to ensure they are
aligned properly. Using the hex bolt driver provided,
tighten each bolt a few revolution at a time until they
are fully tightened. Do not over tighten. Over tightening
could strip the bolts

PARTS LIST

QTY/PCS

DESCRIPTION

HEX BOLT DRIVER

BOLT

1

1

3

1

BASE

EXTENSION POLE

Step 3:Your umbrella base is now ready for use. Carefully guide the
umbrella pole through the hole in the center of the table, and
if applicable, through the hole in the table connector ring, and
then into the base. Using the screw already in place in the
extension pole, turn until your umbrella pole is secure in the
extension pole.

Caution: Although you have an umbrella base, we highly
recommend you remove your umbrella from its base and the
table when not in use. Even when closed, strong winds could
open the umbrella and damage the umbrella or the table.
