7
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
Component list
On/Off Switch
Auxiliary Handle
Spindle Lock Button
Base Plate Angle Scale
Parallel Guide Lock Screw
Base Plate Bevel Lock
Bevel Trac
TM
Parallel Guide
Lower Blade Guard
Base Plate
Lower Guard Lever
Vacuum Adaptor
Fixed Guard
Spindle(See Fig. A)
Inner Flange (See Fig. A)
Saw Blade *(See Fig. A)
Outer Flange (See Fig. A)
Blade Bolt (See Fig. A)
Wrench (See Fig. A)
Depth Of Cut Scale (See Fig. B)
Depth Of Cut Lock Lever (See Fig. B)
* Not all the accessories illustrated or described are included in
standard delivery.
1 2
3
4
5
7 8 9
10
11
12
13
17
14
15
16
18
19
6
17
14
15 16
18
19
A
