10
1
Operating instructions
Note: Before using the tool, read the instruction book carefully.
iNteNDeD USe
The machine is intended for ripping and cross-cutting wood in
straight cutting lines and with bevel angles to 56°, while resting
firmly on the work piece.
cHaNGiNG tHe SaW BlaDe (See fig. a)
• Before any work on the machine itself, unplug the saw.
• Wear protective gloves when mounting the saw blade.
Danger of injury when touching the saw blade.
• only use saw blades that correspond with the characteristic
data given in the operating instructions.
• Do not under any circumstances use grinding discs as the
cutting tool.
For changing the cutting tool, it is best to place the machine on the
face side of the motor housing.
ReMoviNG
Press the spindle lock button (3) and keep it depressed.
• The spindle lock button (3) may be actuated only when the saw
blade is at a standstill.
Loosen the blade bolt (18) with the spanner wrench (19). Remove
the outer flange (17). Tilt back the lower blade guard (9) and hold it
firmly with the lower guard lever (11). Remove the saw blade (16).
MoUNtiNG
Clean the saw blade and all the clamping parts to be assembled.
Tilt back the lower blade guard (9) and hold it firmly with the lower
guard lever (11). Place the saw blade onto the inner flange (15).
Assemble the outer flange (17) and the blade bolt (18). Use the
wrench (19) to tighten the bolt (18) with 1/4 turn more than finger
tight.
• take care that the mounting positions of the inner flange
(15) and outer flange (17) are correct.
• When mounting: ensure that the cutting direction of the
teeth (direction of arrow on saw blade) and the direction-of-
rotation arrow on the blade guard match.
