Rev 0.0/4-14 3 MRTA6-DC2: #35072
SPECIFICATIONS
Description: Designed for use with a crane or other hoisting equipment, MRTA6-DC2 lifters employ vacuum
to hold a load for lifting, and they provide manual 360° rotation and mechanically assisted,
manual 90° tilt movements for load manipulation.
Model Number: MRTA611LDC2 MRTA6FS10TDC2 MRTA610DC2
Vacuum Pads: 1 11" [28 cm] nom. diameter,
lipped (Model G3370)
10" [25 cm] nom. diameter,
w/foam ring (Model VPFS10T) 2
10" [25 cm] nom. diameter,
concave (Model G0750) (6 each, standard rubber)
Pad Spread: 3 ---------------------------- (to outer edges) ----------------------------
Length - Maximum: 104½" [266 cm] 104¼" [265 cm] 102½" [260 cm]
- Minimum: 46¾" [119 cm] 46½" [118 cm] 44¾" [114 cm]
Width - Maximum: 58¾" [149 cm] 58½" [149 cm] 56¾" [144 cm]
- Minimum: 12½" [32 cm] 12¼" [31 cm] 10½" [27 cm]
Maximum Load Capacity: 4
Per-Pad: 184 lbs [83.5 kg] 150 lbs [68 kg] 150 lbs [68 kg]
With 4 Pads: 736 lbs [336 kg] 600 lbs [272 kg] 600 lbs [272 kg]
With 6 Pads: 1100 lbs [500 kg] 900 lbs [410 kg] 900 lbs [410 kg]
Lifter Weight: 180 lbs [82 kg]
Power Source: 12 volts DC, 4.5 amps
Battery Capacity: 7 amp-hours
Rotation Capability: Manual, 360°, with latching at each ¼ revolution (when desired)
Tilt Capability:
Manual, 90°, with four-bar tilt linkage that provides mechanical advantage and tilt locks that
prevent tilt motion when engaged.
Options: Available with Model EO8RC1 - Remote Control System with 310-320 or 433-434 MHz radio
signal, depending on requirements in your geographical location.
See separate instructions about other options.
Operating
Elevation:
Maximum = 6000 feet [1828 meters]
Operating
Temperatures:
32° to 104° F [0° to 40° C]
Service Life: This lifter is designed to have a service life of at least 20,000 lifting cycles, when used and
maintained as intended (vacuum pads, filter elements and other wear-out items are excluded).
ASME Standard BTH-1: Design Category "B", Service Class "0" (see www.powrgrip.com for more information)
!!–CE–!! Note: This symbol appears in the INSTRUCTIONS manual only when requirements of a CE Standard are different from requirements of
other standards that also apply to this vacuum lifter. CE requirements are mandatory in geographical areas where CE Standards apply, but may
be optional in other locations.
1
Optionally available with alternative rubber compounds for special applications (see REPLACEMENTS PARTS LIST).
2
Standard with replaceable, closed-cell foam rings for rough or textured surfaces (see REPLACEMENTS PARTS LIST).
3
The illustrations under ASSEMBLY: T O C HANGE THE P AD F RAME C ONFIGURATION shows the Pad Spread and Maximum Load Capacity
for many of the possible MRTA611LDC pad frame configurations.
4
The Maximum Load Capacity is rated at 16" Hg [-54 kPa] on clean, smooth, nonporous flat surfaces, with a friction coefficient
of 1 (see MAINTENANCE: V ACUUM P AD M AINTENANCE : Pad to Load Friction Coefficient). A qualified person should evaluate the
effective lifting capacity for the actual application. In addition to the effect of friction between the vacuum pads and load, the
lifting capacity may be affected by the following load characteristics: rigidity, strength, surface conditions, overhang, angle, center
of gravity and temperature.
