OPERATING FEATURES

Note: Components shown here are underlined on their first appearance in each section to follow.







1 CONTROL HANDLE

8 TILT RELEASE LEVER

2 VACUUM RESERVE TANKS

9 BATTERY

3 ROTATION RELEASE LEVER

10 EXTENSION ARM

4 BATTERY CHARGER

11 VACUUM PAD with MOVABLE PAD MOUNT

5 LIFT BAR

12 ROTATION WEAR PLATE

6 LIFT BAIL

13 Enclosure with VACUUM PUMP and VACUUM SWITCHES

7 INSTRUCTIONS CANISTER

14 PAD FRAME
