7
R RJ J4 45 5 C Co on nn ne ec ctto orr,, P PIIN N A As ss siig gn nm me en ntt
5 5 S Sp pe ec ciiffiic ca attiio on ns s
E EM MC C
EN 61000-4-2 (ESD) 6kV/8kV
EN 61000-4-3 (radiated immunity)
ENV 50204 @AM 10V/average 80MHz - 1,0GHz
EN 61000-4-4 (burst) ~ 2kV; 2kV; I/O 1kV
EN 61000-4-5 (surge) 2/1kV
EN 61000-4-6 (conducted immunity)
ENV 50204 @10V 150kHz - 80MHz
EN 61000-4-11 (voltage variation)
EN 55022 (HF E)
conducted emissions 150kHz - 30MHz
radiated emissions 30MHz - 1GHz pp/average
radiated emissions 30MHz - 1GHz pp/qp
P PIIN N F Fu un nk kc ciio on n
1 TD+
2 TD-
3 RD+
6 RD-
F Fu un nc cttiio on na all
Compliance ANSI/IEEE 802.3
Data rate 10 /100 Mbit/s
Signalling 10 Base-T / 100 Base-TX
Connectors shielded RJ-45
Segment lenght (max.) 100 m
C Ce errttiiffiic ca attiio on ns s
UL Listed Industrial Control Equipment, certified1 for US and
Canada.
CE marking within the EU
GOST R-certification (IEC standards with Russian deviations)
E En nv viirro on nm me en ntt--tte es stt
IEC 60068-2-1 & IEC 60068-2-2
operating 0°C ... 60°C
non operating -40°C ... 85°C
A Am mb biie en ntt C Co on nd diittiio on ns s
Operation temperature 0°C ... +60°C
Storage temperature -40°C ... +85°C
M Mo ou un nttiin ng g
DIN-rail TS-35 according EN 50022
