Weidmuller IE-SW5-ECO EcoLine Unmanaged Switch - Manual (Page 4)

2 2..1 1 IIn ntte en nd de ed d u us se e
The IE-SW5-ECO is designed for the application in the industrial environment (IP20). The product is
equipped with Ethernet interfaces and serves exclusively for the connecting of components inside of
network. The data communication between these network participants is enable by the connection of
network components.
2 2..2 2 D Diim me en ns siio on ns s
2 2..3 3 F Frro on ntt v viie ew w
4
PWR
Power supply connector
Ethernet interface 1-5
Power LED
Link / Activity LED
Duplex LED
L
D
3
2
1
4
5
