Weidmuller IE-MC-VL Series - Industrial Ethernet Media Converters User Manual
Media converter – value line
Table of contents
Document Outline
- Overview
- Package Checklist
- Features
- Panel Layout of IE-MC-VL Series
- Mounting Dimensions
- DIN-Rail Mounting
- Wall Mounting (Optional)
- ATEX Information
- Wiring Requirements
- Grounding the Media Converter
- Wiring the Alarm Contact
- Wiring the Redundant Power Inputs
- Communication Connections
- Redundant Power Inputs
- Alarm Contact
- Dip Switch Setting
- IE-MC-VL Series DIP switch
- Dip Switch 1 (Default: Off )
- ON: Enables the PORT Alarm. If the port’s link fails, the relay will form an open circuit and the fault LED will light up.
- Off: Disables the corresponding PORT Alarm. The relay will form a closed circuit and the Fault LED will never light up.
- Dip Switch 2 (Default: ON )
- ON: Enables full duplex for 100BaseFX
- Off: Disables full duplex for 100BaseFX
- Dip Switch 3
- Reserved for future use
- To activate the updated DIP switch setting, power off and then power on the Media Converter.
- LED Indicators
- Auto MDI/MDI-X Connection
- Dual Speed Functionality and Switching
- Auto-Negotiation and Speed Sensing
- Specifications
- Technology
- Standards
- IEEE802.3, 802.3u, Link Fault Pass-Through
- Interface
- RJ45 ports
- 10/100BaseT(X)
- Fiber ports
- 100BaseFX (SC, ST connectors available)
- LED Indicators
- Power, Fault, 10/100M, Full Duplex/Collision
- Dip Switch
- Port break alarm mask, 100BaseFx Full/Half duplex selection
- Alarm Contact
- One relay output with current carrying capacity of 1A @ 24 VDC
- Optical Fiber
- Multi mode
- Single mode, 40
- 5
- 40
- 1310
- 1310
- -20
- -5
- -14
- 0
- -34 to -30
- -36 to -32
- 62.5/125
- 9/125
- (1 dB/km, 800 MHz ( km)
- Power
- Input Voltage
- 24 VDC (12 to 45 VDC); Redundant inputs
- Input Current (@24V)
- 0.16 A
- Connection
- Removable Terminal Block
- Overload Current Protection
- 1.1 A
- Reverse Polarity Protection
- Present
- Mechanical
- Casing
- IP30 protection, aluminum case
- Dimensions (W x H x D)
- 53.6 x 135 x 105 mm
- Weight
- 0.63 kg
- Installation
- DIN-Rail, Wall Mounting
- Environmental
- Operating Temperature
- 0 to 60°C (32 to 140 oF),
- Storage Temperature
- -40 to 85°C (-40 to 185 oF)
- Ambient Relative Humidity
- 5 to 90% (non-condensing)
- Regulatory Approvals
- Safety
- UL60950, UL 508, CSA C22.2 No. 60950, EN60950
- Hazardous Location
- ATEX Class I, Zone 2, EEx nC IIC
- EMI
- FCC Part 15, CISPR (EN55022) class A
- EMS
- EN61000-4-2 (ESD), level 3
- EN61000-4-3 (RS), level 3
- EN61000-4-4 (EFT), level 3
- EN61000-4-5 (Surge), level 2
- EN61000-4-2 (CS), level 3
- Shock
- IEC 60068-2-27
- Free Fall
- IEC 60068-2-32
- Vibration
- IEC 60068-2-6
- WARRANTY
- 5 years
