Wasp Barcode WaspLabeler +2D Getting Started User Manual
Page 26

Wasp Labeler User Manual
1.7 Getting Started - Using String Builder to Concatenate Data
In the previous example we learned how to add a data source to the label project and bind an object to
a column within that data source. Now let's learn how to concatenate, or combine, two different
columns. Joined data is called a "string". Creating strings allows you to bind data from two different
columns in your data source to one object. Continuing the Employee Badge example: we previously
bound the column containing the Employee ID to a barcode, now let's bind the Employee First Name
and Employee Last Name columns to a text box.
1.
Add a Text Box Object
.
Click on the barcode icon and drag it to the Design window.
The Properties Box updates with options for the text box.
2. Create a String using String Builder.
On the Properties Box > Content tab, click the String Builder button.
25
