Wasp Labeler User Manual
Move the Properties Box
By default the Properties Box is docked on the right side of the Labeler screen. You can move, or
redock, the Properties Box to the center-left, center-right or left side of the screen as needed.
1. Click on the top of the Properties Box and drag it. The box will undock from it's current
location and appear as a small, floating box similar to the example shown below:
2. Drag the box to the center or left of the screen. Arrows appear on the screen showing you all
dockable locations as shown below:
3. Drag the box to an arrow.. The screen will highlight yellow indicating the area in which the
box will appear if docked there. In the example shown below, the box would appear from the
center of the window to the right.
11
