Enter Configuration Exit and Save Configuration
М$+;О
CODE SELECTION
М$-?О
2/5 FAMILY
disable the family
ÌAC0QÎ
 Read the desired family code  Read a check digit selection
 Interleaved 2/5
ÌAC1TÎ
CHECK DIGIT TABLE
no check digit control
Normal 2/5 (5 Bars)
М12О
МAC2WО
 check digit control and transmission
Industrial 2/5 (IATA)
М23О
МAC3ZО
check digit control without transmission
Matrix 2/5 (3 Bars)
М34О
МAC4]О  Read 4 numbers for the code length
where:
− First 2 digits = minimum code
length.
− Second 2 digits = maximum code
length.
The pharmaceutical code below is part of
the 2/5 family but has no check digit or
code length selections.
The maximum code length is
99 characters.
The minimum code length must always
be less than or equal to the maximum.
Code CIP/HR
МAC5`О Examples:
0199 = variable from 1 to 99 digits in
the code.
1010 = 10 digit code length only.
French pharmaceutical code
68
