WLS8600
4.5 READING PARAMETERS
4.5.1 Trigger Signal
This mode determines how the reading phase is controlled when the hardware
trigger operating mode is selected:
• trigger active level: the reader goes ON when the trigger is pressed and goes
OFF when it is released
• trigger active pulse: the reader goes ON at the first trigger press and goes OFF
only at a second press
4.5.2 Trigger Click
When enabled, it activates a "click" sound upon each trigger pressure.
4.5.3 Trigger-Off Timeout
When this timeout is selected, the reader turns OFF automatically after the desired
period of time.
4.5.4 Reads per Cycle
In general, a reading cycle corresponds to the ON + OFF times of a device.
The resulting effects of this parameter on code reading depend on other related
configuration conditions. Here are the definitions of ON and OFF times.
• For readers using the software trigger parameter (FLASH MODE), a reading
cycle corresponds to the flash on + flash off times. Code reading takes place
during the flash on time.
• For readers using the hardware trigger parameter, a reading cycle corresponds
to a trigger press (ON) + one of the following OFF events:
trigger release (for trigger active level)
a second trigger press (for trigger active pulse)
trigger-off timeout (see par. 4.5.3).
110
