WLS8600
4.6.3 Interdigit Control
The interdigit control parameter verifies the interdigit spacing for code families
Code 39 and Codabar.
4.7 ADVANCED FORMATTING
4.7.1 Match Conditions
Selecting an Advanced Formatting and specifying a Match restriction (Code Type,
Code Length, Predefined Characters) the code will be transmitted according to the
order of the defined formats.
For example, defining 2 formats where:
• Format 1: Match Code type = Code128
• Format 2: Match Code length = 15 and Match with Predefined Characters
“DATA”
a Code128 “DATA:12345ABCDE” with code length 15 will be formatted following the
Format 1.
To send the same code with the Format 2 it is necessary to invert the format order as
follows:
• Format 1: Match Code length = 15 and Match with Predefined Characters
“DATA”
• Format 2: Match Code type = Code128
112
