WLS8600
PEN (continued)
DESCRIPTION STRING
Idle Level normal DE0
inverted DE1
Overflow narrow overflow DH0
medium overflow DH1
wide overflow DH2
Inter-block Delay (100 ms) CK00-CK99
DATA FORMAT
NOT FOR PEN EMULATION INTERFACES
DESCRIPTION STRING
Code Identifier disable EB0
Wasp standard EB1
AIM standard EB2
custom EB3
Custom Code Identifier EHabc
Headers no header EA00
one character EA01x
two characters EA02xx
three characters EA03xxx
four characters EA04xxxx
five characters EA05xxxxx
six characters EA06xxxxxx
seven characters EA07xxxxxxx
eight characters EA08xxxxxxxx
Terminators no terminator EA10
one character EA11x
two characters EA12xx
three characters EA13xxx
four characters EA14xxxx
five characters EA15xxxxx
six characters EA16xxxxxx
seven characters EA17xxxxxxx
eight characters EA18xxxxxxxx
a = ASCII character.
b, c, x = HEX values representing an ASCII character.
a = ASCII character of the WASP STANDARD Code Identifier from the table on page 39.
b = Hex value of the first Custom Code Identifier character from 00 to FD;
FF = disable Code Identifier
c = Hex value of the second Custom Code Identifier character from 00 to FD;
FF = disable second character of Custom Code Identifier
x = Hex value from 00 to FE
124
