The vortex razor hd 1–4x24 riflescope – Vortex Optics RAZOR HD 1-4X24 (MOA) - EBR-556 MOA User Manual
Page 4
4
2
Magnification
Adjustment Ring
Windage
Adjustment Knob
Reticle Focus
Illumination Knob
Objective Lens
Elevation
Adjustment Knob
Battery Cover
MagView
Radius Bar
(3) Turret Cap
Retaining Screws
Zero Reference
Line
The Vortex Razor HD 1–4x24 Riflescope
Fast Focus
Eyepiece
Elevation Knob
Dual Use: Shooting Tactical / Hunting
