Close-up of ebr-556 reticle – Vortex Optics RAZOR HD 1-4X24 (MOA) - EBR-556 MOA User Manual
Page 19
19
18
Note: If you are using the EBR-556 for precision shooting at small
targets, be aware that there is not a 200-yard drop line. When
shooting at 200 yards using center crosshair, the bullet will drop
approximately three inches
when the rifle is zeroed at 100
yards.
The five horizontal
lines below the central
crosshair provide hold-
over references at 300,
400, 500, 600 and 700
yards.
16
17
EBR-556 at 4x
Close-up of EBR-556 Reticle
— Use at 300 Yards
— Use at 400 Yards
— Use at 500 Yards
— Use at 600 Yards
— Use at 700 Yards
EBR-556 Drop Reference marks
Use at 0–200 Yards
