FIG. 1A (GLASS CONFIGURATION DIAGRAM)
4
MODEL VG06042
DIMENSION "B"
(FIXED PANEL) DIMENSION "A"
(DOOR)
34 3/4" x 71 1/4"
7 7/8" x 72"
HEIGHT
72"
LIST
DIMENSIONS
72"
See suggestion of configuration below:
(36"-42") x 72"
(30"-36") x 72" 28 3/4" x 71 1/4"
7 7/8" x 72"
CONFIGURATIONS
1 (A or B)*
CONFIGURATION . 2A
CONFIGURATION . 1A
A
B
A
B
B
A
B
A
CONFIGURATION . 1B
B
A
B
A
CONFIGURATION . 2B
A
B
A
B
2 (A or B)
* Type A means the door panel opens to the left while Type B means to the right.
