Bill of Materials (Cont.)
Following table describes the design specific components of all four versions of PRM ®
evaluation boards.
Table 5.
Design specific components
Reference
Description Manufacturer
Manufacturer
Designator Part Number
Evaluation board numbers: PRD48AF480T400A00 and PRD2A02-xxxxxx
PS10 PRM2A FULL
VICOR
PRM48AF480T400A00
WIDE 400W or PRM2A02-xxxxxx (User Configured)
R26
RES 215K OHM 1/4W
KOA SPEER RK73H2BTTE2153F
1% 1206
R25
RES I SENSE 5m OHM
VISHAY WSL25125L000FEA
1W 1% 2512
F10
FUSE 20A 125VAC
LITTELFUSE 0456020.ER
FAST 10.1X3.1 SMD
PCB
SNGLTD PCB FULL PRM
VICOR 39573
CONFIG CB
Evaluation board numbers: PRD48BF480T500A00, PRD2A01-xxxxxx, PRD48JF480T500A00 and MPRD48NF480M500A00
PRM48BF480T500A00
PS10
PRM2A FULL or PRM2A01-xxxxxx (User Configured)
NARROW 500W
VICOR
or PRM48JF480T500A00
or MPRM48NF480M500A00
R26
RES 174K OHM 1/4W
KOA SPEER RK73H2BTTE1743F
1% 1206
R25
RES I SENSE 5m OHM
VISHAY WSL25125L000FEA
1W 1% 2512
F10
FUSE 20A 125VAC FAST
LITTELFUSE 0456020.ER
10.1X3.1 SMD
PCB
SNGLTD PCB FULL PRM
VICOR 39573
CONFIG CB
Evaluation board numbers: PRD48AH480T200A00 and PRD2A04-xxxxxx
PS10 PRM2A HALF
VICOR
PRM48AH480T200A00
WIDE 200W or PRM2A04-xxxxxx (User Configured)
R26
RES 215K OHM 1/4W
KOA SPEER RK73H2BTTE2153F
1% 1206
R25
RES I SENSE 10m OHM
BOURNS CRA2512-FZ-R010ELF
3W 1% 2512
F10
LITTLE FUSE 10 AMP
LITTELFUSE 0451010.MRL
R451010.MRL
PCB
SNGLTD PCB HALF PRM
VICOR 38693
CONFIG CB
Evaluation board numbers: PRD48BH480T250A00, PRD2A03-xxxxxx , PRD48JH480T250A00 and MPRD48NH480M250A00
PRM48BH480T250A00
PS10
PRM2A HALF NARROW
VICOR
or PRM2A03-xxxxxx (User Configured)
250W or PRM48JH480T250A00
or MPRM48NH480M250A00
R26
RES 174K OHM 1/4W
KOA SPEER RK73H2BTTE1743F
1% 1206
R25
RES I SENSE 10m OHM
BOURNS CRA2512-FZ-R010ELF
3W 1% 2512
F10
LITTLE FUSE 10 AMP
LITTELFUSE 0451010.MRL
R451010.MRL
PCB
SNGLTD PCB HALF PRM
VICOR 38693
CONFIG CB
