Cool-oring, Mechancial drawing – Vicor PI2003-EVAL1 Active ORing Evaluation Board User Manual
Page 7
Picor Corporation • www.picorpower.com
PI2003-EVAL1 User Guide Rev 1.0 Page 7 of 8
Vin1+
Vin2+
Vin1-
Vin2-
Vout-
Vout+
VC2
VC1
R6
R5
D2
D1
FT2
FT1
C1
C2
R1
R2
R3
R4
C3
C4
C5
Q1
Q2
PI2003-EVAL1
rA 6/2008
Cool-ORing
0.000
0.295
0.500
0.895
1.100
1.300
1.600
1.800
0.000
0.150
0.830
1.650
1.800
0.000
0.535
0.650
1.145
1.450
1.800
Mechancial Drawing
Figure 6a – PI2003-EVAL1 layout top layer. Scale 2.0:1
Figure 6b – PI2003-EVAL1 layout Bottom layer. Scale 2.0:1
