background image

UG:100

vicorpower.com

Applications Engineering: 800 927.9474

Page 8

Thermals

For most lab environments a fan blowing across the evaluation board is recommended
See VI Brick® Thermal Management Application Note at:

www.vicorpower.com/documents/application_notes/AN200_VIBrickTherm.pdf

or contact Vicor Applications Engineering for assistance (800) 927-9474.

Ordering Information

Two models of the evaluation board are available:

Order Number

Power Module On PCB

AC-DC Format

PFM-DISCRETE-FILTR

PS01 PFM175D480C330A00

VI Chip

PFB-DISCRETE-FILTR

PS02 PF175B480C033FP-00

VI Brick

Ref. Des. Description

Digi-Key

Manufacturer

Digi-Key

Part Number

Future

Manufacturer

Future

Part Number

C01

CAPY X7R 4700pF 10% 250V 2220

Murata

490-3482-2-ND

Murata

GA355DR7GF472KW01L

C02

NOT APPLIED

NOT APPLIED

NOT APPLIED

NOT APPLIED

NOT APPLIED

C03

CAPY X7R 4700pF 10% 250V 2220

Murata

490-3482-2-ND

Murata

GA355DR7GF472KW01L

C04

NOT APPLIED

NOT APPLIED

NOT APPLIED

NOT APPLIED

NOT APPLIED

C09

CAP X7R .1uF 10% 25V 0805

Kemet

399-1170-2-ND

AVX

08053C104KAT2A

C10

C11

C12

CAPY X7R 4700pF 10% 250V 2220

Murata

490-3482-2-ND

Murata

GA355DR7GF472KW01L

C13

NOT APPLIED

NOT APPLIED

NOT APPLIED

NOT APPLIED

NOT APPLIED

C15

0.47uF/20/275VAC X2 CAP

Kemet

399-5429-ND

Wima

MKS4 0.47/630/10 PCM 27.5

C17

CAP X7T 0.47uF 10% 630V 2220

TDK

445-8876-2-ND

TDK

C5750X7T2J474K

C18

C19

C20

C21

CAP X7R .015uF 10% 630V 1206

TDK

445-4489-2-ND

TDK

C3216X7R2J153M

C22

CAP X7R 4.7uF 10% 25V 0805

TDK

445-5972-2-ND

TDK

CL21A475KAQNNNG

C23

CAP X7T 0.033uF 10% 630V 1206
.060MAXHT

TDK

445-7762-2-ND

Yageo

CC1206KKX7RZB333

C24

CAP X7T 0.47uF 10% 630V 2220

TDK

445-8876-2-ND

TDK

C5750X7T2J474K

C25

C29

NOT APPLIED

NOT APPLIED

NOT APPLIED

NOT APPLIED

NOT APPLIED

C30

CAP X7R 1.0uF 10% 100V 1206

TDK

445-4467-2-ND

TDK

C3216X7R2A105K

C31

C32

C33

C34

C35

CAP ALUM 100UF 63V 20% RADIAL

Nichicon

UVY1J101MPD-ND

Nichicon

UVY1J101MPD

C37

CAP ALEL 6800uF 20% 63V 25X50

Kemet

493-1135-ND

Nichicon

UVZ1J682MRD

D01

DPN 1000V 8A DO214AB

Diodes Inc

S8MCDITR-ND

Diodes Inc

S8MC-13

D02

D03

DPN 1000V 5A SMC

*Stocked by Arrow NAC, Manufacturer: Taiwan Semiconductor, Part#: HS5M R7

D04

Bill of Materials
