MegaCam 800
Camera
2
Introduction
The high sensitivity cooled CCD MegaCam 800
Camera is designed for use with UVP’s
BioSpectrum Imaging Systems. The instruction manual covers assembly of the camera and lens to
the BioSpectrum darkroom and installation of software.
Refer to the BioSpectrum Manual for additional system information and the VisionWorksLS Software
PDF Manual on the Support CD or Help Files embedded in the software for more information.
Applications the MegaCam 800Camera is designed for:
Luminescence detection
Chemiluminescent samples including westerns, northerns, southerns and in vivo/in vitro samples
Autoradiograph films
Fluorescent and colorimetric gels, colony and microtitre plates, dot blots, membrane arrays
Components
Camera Kit
The camera kit includes a motorized lens. Refer to the packing slip or installation components list for a
complete list of parts.
MegaCam 800 Camera
Cables
Power supply for the camera
Motorized lens
Brackets/screws for each lens
Back Focus Rings (Note: Back focus rings may not be required for your camera. If no rings are
needed there will not be any rings shipped with your order.)
Additional components as described in the packing slip/components list
The MegaCam 800 Camera specifications include:
Camera Specifications
MegaCam 800
Type
80mm x 13.5mm full frame CCD
Resolution
3326 x 2504
Pixel Size
5.4µm x 5.4µm
Full Well Capacity
25,000 electrons
Bit Depth
16-bit
Readout Noise
10 electrons (typical)
Quantum Efficiency
(62% @ peak) 400nm 40%;
500nm 58%; 600nm 58%
Cooling
-5
0˚ C from ambient
Binning
Yes
PC Interface
USB
Lens Mount
T-Mount
Lens
50mm f /1.2 or
30mm f/1.4 or
28mm f/1.8 or
Lens Controller
Control box
AC power
USB cable
USB driver
