Steel
Door Panel
Dimensions
6.4 2014 (U1 REVISED) Comp 6
6/8 Steel Entry Doors
E
D
F
G
A
C B
Full Lite Flush
(1664) (108N, 118N, 128N, 2064)
(108, 118, 128, 198, 916, 2264)
(Impact - 118H, 108H, 118NH, 108NH,
128H, 128NH, 198H, 916H, 916NH)
(Slab-DR100U1 & TS100U1 & PDU1)
Note:
For Optional Grille Locations,
See Arch 1.
Daylight Opening: 14-31/32" x 62-31/32"
(1664) (941 sq.in.)
Daylight Opening: 20-15/16" x 62-15/16"
(2264) (1317 sq.in.)
Size A B C
D
(6/6 & 6/8)
D
(7/0) F
G
(6/6)
G
(6/8)
G
(7/0)
2/4 27-25/32" 4-29/32" 17-31/32" 4-3/16" N/A 65-31/32" 6-9/16" 8-57/64" N/A
2/6N 29-25/32" 3-61/64" 21-7/8" 4-5/32" 7-3/16" 65-7/8" 6-11/16" 9-1/64" 9-63/64"
2/8N 31-25/32" 23-7/8" 4-5/32" 7-3/16" 65-7/8" 6-11/16" 9-1/64"
2/8 31-25/32" 21-7/8" 4-5/32" 7-3/16" 65-7/8" 6-11/16" 9-1/64"
2/10 33-25/32" 23-7/8" 4-5/32" 7-3/16" 65-7/8" 6-11/16" 9-1/64"
3/0 35-25/32" 23-7/8" 4-5/32" 7-3/16" 65-7/8" 6-11/16" 9-1/64"
3/6 41-25/32" 23-7/8" 4-5/32" 7-3/16" 65-7/8" 6-11/16" 9-1/64"
3-61/64"
4-61/64"
4-61/64"
5-61/64"
8-61/64"
9-63/64"
9-63/64"
9-63/64"
9-63/64"
9-63/64"
Height E
6/6 76-23/32"
6/8 79-3/64"
7/0 83-3/64"
Daylight Opening: 18-29/32" x 62-29/32"
(2064) (1189 sq.in.)
21-1/2"
F
C
D
A
Half Lite 2 Panel Flush
(Glass - 104, 137, 612, 904, 2236)
(Impact Glass - 104H, 612H, 904H)
(Slab - HD210U1, HD254U1, HD210NU1,
HD254NU1 & TS210U1, TS254U1)
23-1/2"
Size A B C
2/8 31-25/32" 3-15/16" 4-5/32"
2/10 33-25/32" 4-15/16" 5-5/32"
3/0 35-25/32" 5-15/16" 6-5/32"
9-1/2"
37-29/32"
23-29/32"
E
Daylight Opening: 20-15/16" x 34-15/16"
(729 sq.in.)
Height D E F
6/8 79-3/64" 4-5/32" 9-7/64"
7/0 83-3/64" 7" 13-7/64"
B
Note:
For Optional Grille Locations,
See Arch 1.
