Steel
Door Panel
Dimensions
Comp 6 2014 (U1 REVISED) 6.23
6/8 Steel Edge Doors
B 9”
3”
C
D
25-3/8”
4-5/8”
6-9/16”
21-1/2”
E
7”
A
B 9”
5”
C
37-1/8”
D
6-1/2”
21-1/2”
E
Size A
2/8 31-3/4” 4-3/8”
2/10 33-3/4” 5-3/8”
3/0 35-3/4” 6-3/8”
Height C E
6/8 5-3/8” 78-15/16” 8-7/16”
7/0 7-3/8” 82-15/16” 10-7/16”
Height C E
6/8 5-3/8” 78-15/16” 8-1/2”
7/0 7-3/8” 82-15/16” 10-1/2”
6 Panel Flush
(Slab Undersize - SE210N)
4 Panel Square Top Flush
(Slab Undersize - SE214)
29-3/4”
4-3/8”
D
B
D
Note: 2/6 only.
Size A B
2/6 29-3/4" 4-3/8"
