Therma-Tru COMP 6 Steel Door Panel Dimensions - U1 Revised - Manual (Page 14)

Steel
Door Panel
Dimensions
6.14 2014 (U1 REVISED) Comp 6
6/8 Steel Entry Doors
B
A
23-13/16”
5-9/32”
9-9/32”
50”
79-3/64”
4”
12”
7-49/64”
4” 9-29/32”
17-23/32”
41-25/32”
9-29/32”
79-3/64”
7-49/64”
4”
9-29/32”
C
A
B 23-7/8 ”
48-7/8 ”
6-1/4”
12”
4-5/32 ”
Size A B
2/8 31-25/32” 3-63/64”
2/10 33-25/32” 4-63/64”
3/0 35-25/32” 5-7/8”
Size A B C
2/8 31-25/32” 3-61/64” 3-63/64”
2/10 33-25/32” 4-61/64” 4-63/64”
3/0 35-25/32” 5-61/64” 5-63/64”
3/4 Scroll Top Oval
2 Panel Flush
(1640)
(Slab - HD750U1)
3/4 Lite 2 Panel Flush
(2247)
(Impact - 2247H)
(Slab - HD031U1)
Daylight Opening: 14-23/32" x 38-25/32"
(442 sq.in.)
Daylight Opening: 21-1/8" x 46-1/8"
(974 sq.in.)
Note:
For Optional Grille Locations,
See Arch 1.
