Therma-Tru COMP 8 Sidelite Panel Dimensions - U1 Revised - Manual (Page 31)

Sidelite
Panel
Dimensions
Comp 8 2014 (U1 REVISED) 8.31
6/8 Steel Sidelites
A
B
9-7/8”
4-5/32”
37-7/8”
6-7/16”
21-1/2”
9-9/32”
79-1/4”
9-1/2” C
A
B
Size 12” 14”
11-15/16”
1-1/32”
13-15/16”
2-1/32”
C 1-7/32” 2-7/32”
3/4 Lite
Sidelite
1 Panel Flush
(847)
(Impact - 0847H)
(Profiles Sidelite
HDSLEB34)
12”
14”
Size A B
11-15/16”
13-15/16”
1-1/32”
2-1/32”
9-7/8”
A
B
79-1/4”
4-5/32”
6-9/32”
7-15/16”
48-7/8”
12”
B 9-7/8”
9-29/32”
7-15/16”
6-23/32”
6-15/32”
12”
46-1/8”
79-1/4”
A
9-29/32”
12”
14”
Size A B
11-15/16”
13-15/16”
1-1/32”
2-1/32”
Half Lite RT
Sidelite
1 Panel Flush
(152, 153, 0836)
(Profiles Sidelite
HDSLEB8)
(Traditions
Sidelite SLEB8)
3/4 Scroll
Sidelite
1 Panel Flush
(844)
(Profiles Sidelite
HDSLEB34)
Daylight Opening:
6-15/16" x 45-15/16"
(318 sq.in.)
Daylight Opening:
6-29/32" x 34-29/32"
(241 sq.in.)
Daylight Opening:
7-1/8" x 43-3/8"
(289 sq.in.)
A
B
79-3/16"
25 1/2"
21 1/2"
9 3/32"
C 9 1/2"
1 Lite Sidelite 2
Panel Flush
(Glass - 296, 996,
0806)
(Profiles Sidelite -
HDSLEB8)
(Traditions
Sidelite - SLEB8)
Size 12" 14"
A 11-15/16" 13-15/16"
B 1-1/32" 2-1/32"
C 1-7/32" 2-7/32"
Daylight Opening:
6-15/16" x 4-15/16"
(34 sq.in.)
7 15/16"
9 15/16"
4 1/4"
4 9/32"
