Page 17
Sidelite
Panel
Dimensions
Comp 8
2014 (U1 REVISED)
8.17
8/0 Fiber-Classic Mahogany Sidelites
A
C
F
B
D”
E
95-1/4”
Size
A
B
C
D
E
12”
11-15/16”
1-1/16”
9-13/116”
82”
8”
12” Impact 11-15/16”
1-1/8”
9-11/16”
81-7/8”
8-1/16”
14”
13-15/16”
2-1/16”
9-13/16”
82”
8”
14” Impact 13-15/16”
2-1/8”
9-11/16”
81-7/8”
8-1/16”
8’ Full Lite Sidelite w/ Stile Lines
(0780)
(Impact - 700H)
(Sidelite-SL8FCM02)
F
5-1/4”
5-5/16”
5-1/4”
5-5/16”
Daylight Opening: 6-7/8" x 79-1/16"
(545 sq.in.)
8’ Full Lite Sidelite Flush
(7085, 0780)
(Impact - 700H, 706H)
(8/0 Sidelite - SL8FCM1)
(8/0 U3 Sidelite - SL8FCM1U3
A
B
C
G
F
D
E
*U3 Sidelites are intended
for Venting sidelite applications.
Daylight Opening: 6-7/8" x 79-1/16"
(545 sq.in.)
Size
A
B
C
D
12"
11-15/16" 1-1/32"
9-27/32" 82-1/32"
12" Impact 11-15/16" 1-21/32" 9-11/16"
81-7/8"
14"
13-15/16" 2-1/32"
9-27/32" 82-1/32"
14" Impact 13-15/16" 2-21/32" 9-11/16"
81-7/8"
Size
E
F
G
12" 8/0
7-13/16" 5-13/32"
95-1/4"
12" 8/0 Impact
7-27/32" 5-13/32"
95-1/4"
14" 8/0
7-13/16" 5-17/32"
95-1/4"
14" 8/0 Impact
7-27/32" 5-17/32"
95-1/4"
12" 8/0 U3
7-39/64" 5-13/32" 95-3/64"
12" 8/0 Impact U3 7-41/64" 5-13/32" 95-3/64"
14" 8/0 U3
7-39/64" 5-17/32" 95-3/64"
14" 8/0 Impact U3 7-41/64" 5-17/32" 95-3/64"
