Sidelite Panel
Dimensions
8.22 2014 (U1 REVISED) Comp 8
8/0 Fiber-Classic Oak Sidelites
8’ Half Lite
Sidelite
1 Panel
(0847)
(Impact - 0847H)
(Sidelite -
SL8FCO2)
C
B
A
8-1/8”
26-1/8”
5-5/32”
9-7/8”
48-7/8”
6-23/32”
8-3/8”
95-1/4”
8’ Full Lite Sidelite w/ Stile Lines
(0780)
(Impact - 700H)
(Sidelite - SL8FCO2)
A
C
F
B
D”
E
95-1/4”
C
B
A
5-1/4”
8-1/8”
65-7/8”
13”
8-3/8”
8-7/8”
2-3/4”
95-1/4”
Size 12” 14”
A 11-15/16” 13-15/16”
B 1-1/32” 2-1/32”
C 1-13/16” 2-13/16”
Size 12” 14”
A 11-15/16” 13-15/16”
B 1-17/32” 2-17/32”
C 1-13/16” 2-13/16”
Size A B C D E
12” 11-15/16” 1-1/16” 9-13/16” 82-1/32” 7-13/16”
12” Impact 11-15/16” 1-1/8” 9-11/16” 81-7/8” 7-27/32”
14” 13-15/16” 2-1/16” 9-13/16” 82-1/32” 7-13/16”
14” Impact 13-15/16” 2-1/8” 9-11/16” 81-7/8” 7-27/32”
8’ 3/4 Lite
Sidelite
1 Panel
(0764)
(Impact - 0764H)
(Sidelite -
SL8FCO2)
F
5-13/32”
5-17/32”
5-13/32”
5-17/32”
Daylight Opening:
6-15/16" x 45-15/16"
(318 sq.in.)
Daylight Opening:
5-15/16" x 62-15/16"
(373 sq.in.)
Daylight Opening: 6-7/8" x 79-1/16"
(545 sq.in.)
