Sidelite Panel
Dimensions
8.26 2014 (U1 REVISED) Comp 8
6/8 Smooth-Star Sidelites
C
B 9-7/8”
9”
9-9/16”
6-23/32”
3-13/16”
13”
46-5/32”
A
3/4 Scroll
Sidelite
1 Panel
(0844S)
(Sidelite-SLSS2)
12” 14” Size
A 11-15/16” 13-15/16”
B 1-1/32” 2-1/32”
2-15/32” 1-15/32” C
79-1/4”
C
B 9-7/8”
9”
9-9/16”
4-5/32”
3-21/32 ”
13”
48-7/8”
79-1/4”
A
12” 14” Size
A 11-15/16” 13-15/16”
B 1-1/32” 2-1/32”
2-15/32” 1-15/32” C
This space intentionally left blank.
9-7/8 ”
B
A
4-3/16 ”
37-7/8 ”
79-1/4 ”
5-13/16 ”
21-13/16 ”
9-9/16 ” 9 ”
C
11-15/16” 13-15/16”
1-1/32” 2-1/32”
1-15/32” 2-15/32”
B
A
Size
C
12” 14”
3/4 Lite
Sidelite
1 Panel
(0847)
(Impact - 0847H)
(Sidelite-SLSS2)
Half Lite RT
Sidelite
1 Panel
(153, 152)
(Sidelite-SLSS2)
Daylight Opening:
6-15/16" x 45-15/16"
(318 sq.in.)
Daylight Opening:
7-1/8" x 43-3/8"
(289 sq.in.)
Daylight Opening:
7-1/8" x 35-1/8"
(250 sq.in.)
