TerraWave RMFLT-2-2400N User Manual
TerraWave Hardware

TerraWave Solutions
®
2.4 GHz 2-Way Splitter with N-Style Jack Connector
Specifications
Model
RMFLT-2-2400N
Frequency Range
1700 - 2500 MHz
Insertion Loss
≤ 3.5 dB
Isolation
≥ 20 dB
VSWR
≤1.4
Impedance
50 Ω
Maximum Power
50 Watts
Connector
N-Style Jack
Operating Temperature Range
-22°F to +140°F
Humidity
5 % – 95 %
Dimensions
4.6” x 3.3” x 0.8”
Weight
8.5 ounces
TerraWave’s antenna splitters are designed to divide or “split” the RF signal from one radio to
multiple antennas. The splitters are perfect for applications that require coverage of two different
areas with a single access point or bridge. The units’ rugged design and small footprint make
them ideal for most outdoor bridging and WLAN applications. Each splitter includes a one-year
warranty. Visit www.terrawave.com for additional information.
Note: Requires two splitters per AP when using diversity
Features and Benefits:
•
Provide RF coverage in separate areas with a
single access point or bridge
•
Compact, lightweight design
•
Easy to mount
•
High isolation, low insertion loss and minimal
VSWR
•
N-Style Jack connector included
•
Excellent value - Superior performance at a
competitive price
www.terrawave.com Email: [email protected] Phone: 210-375-8482 or 800-851-4965 10521 Gulfdale, San Antonio, TX 78216
