Single Port, 10KA, 1 GB Ethernet Surge Suppressor for 802.3at
TerraWave's Ethernet surge suppressor offers advanced in-line, bi-directional lightning and surge protection for
Ethernet powered devices. This suppressor is CAT5/CAT5e/CAT6 compatible and includes a single port with
shielded RJ45 jacks and metal housing for EMI noise suppression. It is for 802.3at power. Every TerraWave
Ethernet surge suppressor is covered by the Company’s one-year warranty program. For questions and to
purchase product, contact a regional sales executive at 210-374-8482, 800-851-4965 or [email protected].
Visit www.terrawave.com for additional information.
www.terrawave.com Email: [email protected] Phone: 210-375-8482 or 800-851-4965 10521 Gulfdale, San Antonio, TX 78216
Specifications
Model TW-SP-1GBPS-10-1T
Operating Voltage
Data: 5V PoE: 48V
Break Down Voltage
Data: 90V PoE: 90V
Impulse Protected Voltage
<250V
Max Surge Discharge Current
(8/20uS) 10KA
Peak Pulse Current
100A (10/1000uS)
Max Shunt Capacitance
Power & Data: <2.5pF
Insulation Impedance
≥ 1000M Ohm
Data Rate
1000 Mbps
Response Time
<5 nS
Ground Wire
14 AWG
Dimensions (w/ bracket)
4.7" (L) x 1.0" (W) x 1.0" (H)
Weight
0.23 lbs
Operating Temperature Range
-40°F to +185°F
Storage Temperature Range
-40°F to +257°F
Operating Humidity
0-95% non-condensing
