TerraWave M6060060MO1D43607 User Manual
Specifications

TerraWave’s Dual Band 6 dBi Outdoor MIMO Omni Antenna is designed to operate enterprise class
802.11ac/802.11n MIMO access points. With dual-band leads, each of the four cables support both 2.4 and 5
GHz, making it an ideal and aesthetically pleasing antenna to support demanding outdoor applications. The
rugged enclosure makes this antenna perfectly suited for use in a warehouse or manufacturing environment
where it must withstand exposure to moisture and dust. Includes an L-Bracket for mast and or wall mounting.
Industrial beam clamps are available as an additional option. Every TerraWave antenna is covered by the
company’s two-year TerraNet warranty program. For questions and to purchase product, contact a regional
sales executive at 210-375-8482, 800-851-4965 or [email protected].
Specifications
Model
M6060060MO1D43607
Frequency Range
2400~2500 MHz
5150~5850 MHz
Bandwidth
100 MHz
700 MHz
Gain
6 dBi
Vertical Beamwidth
45°
20°
Horizontal Beamwidth
360°
VSWR
≤2.0
≤2.2
Nominal Impedance
50 Ohms
Polarization
Vertical
Isolation
≤
-15dB
Max Power
10W
Lightning Protection
Not DC Grounded
Connector
N-Style Plug with 36” Cable
Dimensions
5.9” x 7”
Weight
2.64 lbs
Mast Mount Diameter
1.37”-1.97”
Operating Temperature Range
-40°F to +158°F
Wind Load
134 mph
E-Plane Pattern H-Plane Pattern
2.4 GHz
E-Plane Pattern H-Plane Pattern
5 GHz
