2.4 GHz 6 dBi Fiberglass
Omnidirectional Antenna with N-Style Jack Connector
TerraWave's 6 dBi fiberglass omnidirectional antenna is designed for indoor and outdoor 2.4 GHz wireless
local area networks. It features a UV stable, vented radome that provides ultimate sustainability against
extreme weather conditions such as high temperature, strong winds and rain. It can be mast, ceiling or wall
mounted. Includes a durable mounting bracket. Every TerraWave antenna is covered by the Company’s two
-year TerraNet warranty program. For questions and to purchase product, contact a regional sales executive
at 210-375-8482, 800-851-4965 or [email protected]. Visit www.terrawave.com for additional
information.
Specifications
Model
T24060O10006
Frequency Range
2400 ~ 2483 MHz
Bandwidth
83 MHz
Gain
6 dBi
Polarization in Vertical Plane
28°
Polarization in Horizontal Plane
360°
VSWR
-/=1.5
Nominal Impedance
50 Ohms
Polarization
Vertical
Max Power
100 Watts
Connector
N-Female
Length
15.8”
Weight
1.4 lb. (w/ bracket)
Rated Wind Velocity
135 mph
E-Plane H-Plane
