PERFORMANCE SERIES
2.4 GHz 6 dBi Fiberglass Omni Antenna with Side Mount and N-Style Jack Connector
TerraWave’s 6 dBi fiberglass omnidirectional antenna is designed for indoor and outdoor
2.4 GHz wireless local area networks. It features UV stabilized radome that provides ultimate
sustainability against extreme weather conditions such as high temperature, strong winds and rain.
Includes a sturdy side mount for convenient mast or wall mounting. Every TerraWave antenna is
covered by the company’s two-year TerraNet warranty program. Visit www.terrawave.com for
additional information.
E-Plane H-Plane
Specifications
Model
T24060O10006S
Frequency Range
2400 ~ 2483 MHz
Bandwidth
83 MHz
Gain
6 dBi
Horizontal Beamwidth
360°
Vertical Beamwidth
25°
VSWR
≤ 1.5
Nominal Impedance
50 Ohms
Maximum Power Rating
100 Watts
Polarization
Vertical
Connector
N-Style Jack
Length
15”
Wind Load
120 mph
Radome
White Fiberglass
Operating Temperature Range
-22°F ~ 158°F
Mast Mount Diameter
Ш1.5” ~ Ш2.0”
