TerraWave T24050O14820M - Manual

TerraWave Solutions
®
2.4 GHz 5 dBi Mast Mount Omni Antenna with RPSMA Plug Connector
TerraWave's 2.4 GHz 5 dBi omnidirectional antenna is designed for indoor and outdoor wireless
local area networks. It features a UV stabilized radome that provides ultimate sustainability against
extreme weather conditions such as high temperature, strong winds and rain. Includes an RPSMA
plug with a 48” pigtail and a mast mount.
10521 Gulfdale San Antonio, TX 78216 www.terrawave.com www.tessco.com/go/terrawave Phone: 800-472-7373 Fax: 410-527-0005
Specifications
Model T24050O14820M
Frequency Range 2400 - 2483 MHz
Bandwidth 83 MHz
Gain 5 dBi
Vertical Beamwidth 28°
Horizontal Beamwidth 360°
VSWR -/=1.5
Nominal Impedance 50 Ohms
Polarization Vertical
Max Power 50 Watts
Connector RPSMA Plug with 48” Pigtail
Height 13.4”
Weight 0.44 lbs
Operating Temperature Range -22°F to +158°F
Rated Wind Velocity 135 mph
Vertical Radiation Pattern Horizontal Radiation Pattern
