TerraWave M6060060MP1D43620 - Manual

TerraWave's 2.4/5 GHz 6 dBi quad patch multiple-input and multiple-output (MIMO) antenna is designed to be
operated with any manufacturer’s enterprise-class 802.11n MIMO access points. The antenna comes with four RPSMA
Plug connectors and 36” cables. With dual-band leads, each cable supports both 2.4 and 5 GHz, making it an ideal and
aesthetically pleasing antenna to support demanding outdoor applications in next generation IEEE 802.11n wireless
communication systems. The antenna radome is designed to withstand challenging environments where there is
exposure to moisture and dust and comes with an articulating mount. All TerraWave antennas are covered by the
Company’s two-year TerraNet warranty program. For questions and to purchase product, contact a regional account
executive at 210-375-8482, 800-851-4965 or [email protected]. Visit www.terrawave.com for additional
information.
Specifications
Model M6060060MP1D43620
Frequency Range 2400 ~ 2500 MHz 5150 ~ 5850 MHz
Gain 6 dBi
Vertical Beamwidth 80±20° 45±20°
Horizontal Beamwidth 80±20° 45±20°
VSWR ≤ 2.0 ≤ 2.5
Front-to-back ratio ≥18
Polarization Vertical
Max Power 100 Watts
Connector RPSMA Plug
Pigtail Length 36” (w/ Connector)
Dimensions 9.2” x 9.0” x 1.1”
Weight 2.65 lbs
Operating Temperature Range -40°F to +140°F
Mounting Style Wall or Mast/Pole
2.4 GHz 5 GHz
