wireless infrastructure
www.ventev.com [email protected] 800-851-4965
© 2013 Ventev
MOUNTING INSTRUCTIONS
TerraWave High-Density 2.4/5 GHz 10/11 dBi Ceiling-Mount Antenna
With N-Style Jack Connector
Figure 1
1. Drill 1” hole in ceiling tile
(See Figure 1).
2. Pull leads through drilled hole and
ensure antenna is flush against ceiling
tile
(See Figure 2)
.
3. Tighten screw mount until antenna is
securely fastened
(See Figure 3)
.
4. Insert ceiling tile into grid.
Figure 2
Figure 2a (Close-Up)
Figure 3
