Telematrix SP200 User Manual
Page 9
9
1
Data Port ....................................
Convenient port to connect a computer,
modem, fax or answering device.
2
Line Jack ………………………………………... Modular receptacle for connecting the
line
cord.
3
Headset Jack ..............................
Convenient RJ port or 2.5mm coaxial port
used to connect an optional headset.
4
Handset Jack .............................. Connection for handset coil cord.
5
Power Adapter Receptacle ……..…….
For optional coaxial power adapter.
6
Low Voltage MW Switch ………………… Selects low voltage message waiting.
7
Hold Key Switch ……………...……………. Used to select line hold or system hold.
8
Elevation Stand Lock …………………….
Used to “lock” the elevation stand.
