Schwank bistroSchwank 2-Stage User Manual
Page 10
2100 / IO 100 Manual
IM110107
RD: MAY 2014
R.L. 4A
10
Table 3: INDOOR - MINIMUM MOUNTING & CLEARANCES TO COMBUSTIBLES
The clearance to combustible material represents the minimum distance that must be main-
tained between the outer heater surface and a nearby surface. The stated clearance to com-
bustibles represents a surface temperature of 90F° (50C°) above indoor room temperature.
It is the installer’s responsibility to ensure that building materials with a low heat tolerance
which may degrade at lower temperatures are protected to prevent degradation. Examples of
low heat tolerance materials include awnings, vinyl siding, fabrics, some plastics, filmy materi-
als, etc.
Note: Do not store or place anything directly under heater
Ensure mounting height in any location is sufficient to prevent patrons from
coming in contact with heater, and clearance to combustibles is maintained.
Figure 3: INDOOR - MOUNTING CLEARANCES
MODEL NO
Ends
HORIZONTAL
UP TO MAXIMUM 30° ANGLE
E
A
S
T
B
F
2135 / IO-135 -N\L 14” 18”
18”
20”
11”
60”
2150 / IO150 -N\L
14” 21”
23”
25”
10”
62”
MH
108”
120”
MA
102”
114”
CH
138”
153”
CA
132”
147”
Under
U
45”
60”
Table 4: INDOOR - SUGGESTED MOUNTING HEIGHT FOR COMFORT
MOUNTING
PARAMETERS ***
MODEL
2135 / IO-135
35,000 Btuh
MODEL
2150/2152 / IO-150/152
50,000 Btuh
Mounting angle
Horizontal
30
0
Horizontal
30
0
Suggested height above deck/floor
9’ 6”
9’ 0”
10’ 6”
10’ 0”
NOTE: MOUNT HEATER AT MAXIMUM 30° ANGLE TO AVOID DAMAGE
