60
S100-F / ITB-F I&O Manual
IM101230
RD: SEP 2014
RL: 11A
# PART DESCRIPTION PART # PART DESCRIPTION PRIMARY SUPPLEMENT
Burners with FENWAL IGNITION CONTROL - Models: S100-F; ITB-F; S100-FB; ITB-FB
20 FENWAL DSI CONTROL JA-0567-XX 3-Trial 24Vac with blower relay -F; -FB Models
REPLACEMENT KIT: FENWAL CONTROL JA-0568-KT
Fenwal Control + Wire Harness + Cable + Igniter: Replaces Fenwal & S87J
21 IGNITION CABLE JS-0518-SA Hi voltage wire (24") STW - 2 x 1/4" Spades
Burners with HONEYWELL S87-J IGNITION CONTROL - Models: S100/ITB; “-H”; “-HA”; “-HS”
20 HONEYWELL IGNITION CONTROL JA-0568-XX DISCONTINUED - NO LONGER AVAILABLE
REPLACEMENT KIT: WITH FENWAL DSI JA-0568-KT
Fenwal Control + Wire Harness + Cable + Igniter: REPLACES S87J
21 IGNITION CABLE HONEYWELL S87J JS-0518-XX Wire hi voltage (24") S87J Bullet Connection
Burners with CHANNEL GASLITER MICRO 50N IGNITION CONTROL - Models: S100-C; ITB-C
20 CHANNEL MICRO 50N IGNITION CONTROL JB-0568-AA
3 Try Potted MICRO 50N DSI - Replaces existing MICRO 50N Control
Wiring Harness (not shown) JB-0568-WH-
Wiring Harness for connection of MICRO 50N
21 IGNITION CABLE JS-0518-SA Hi voltage wire (24") STW - 2 x 1/4" Spades
